BENEFITS
-The dise plough is designed to work in all types of soil forbasic functions such as soil breaking,
soil. raising, soil turning and soil mixing.
-It is used to open the new fields and to process the stony area.
-It can be used easily at rocky and rooted area.
-It is especially useful in hard and dry trashy land conditions and in soils where scouring is a major problem.
FEATURES
-In conformity with the soil conditions it is being produced with 2, 3, 4, & 5 bottoms version with an option for extra kit for converting it to extra bottom plough.
-It is directly mounted to the tractors.
-Extra heavy duty pipe frame has high trash clearance allowing the plough to operate under heavy crop residue.
Specifications
| Model | 2 Bottom | 3 Bottom | 4 Bottom | 5 Bottom |
|---|---|---|---|---|
| Tractor power (HP) | 50-60 | 65-75 | 75-90 | 100-125 |
| Axle type | Seamless tubular frame | Seamless tubular frame | Seamless tubular frame | Seamless tubular frame |
| Length | 1800 mm | 2400 mm | 3000 mm | 3600 mm |
| Mounted CAT. | CAT-II | CAT-II | CAT-II | CAT-II/III |
| Discs | 660 x 6T (26") | 660 x 6T (26") | 660 x 6T (26") | 660 x 6T (26") |
| Bearing Hubs | 2 | 3 | 4 | 5 |
| Weight (kgs. (Approx.) | 310 | 415 | 510 | 620 |
*The weight and working data contained in the present leaflet are supplied for information only and are not binding. Specification and size can be altered as part of ongoing product modification/improvement.
