BENEFITS
-Suitable for use in stone and root obstructed soil. It is designed for toughest operations
-Used for loosing and aerating soil to a depth of 9
-Prepares seeds beds quickly and economically
FEATURES
-When one tynes strikes a hidden object, the others continue to work at the correct depth.
-Spring loaded assemblies derive their strength from heavy duty angles, which once fixed to the immensely strong main frame cannot move or strain out of position.
Specifications
| Size | 9 Tyne | 11 Tyne | 13 Tyne | 15 Tyne |
|---|---|---|---|---|
| Power Required (HP) | 40 - 45 | 50 - 55 | 60 - 65 | 70 - 75 |
| Frame | 75x50 mm (Channel) | 75x50 mm (Channel) | 100x50 mm (Channel) | 100x50 mm (Channel) |
| Tynes | 50x25 mm (Forged) | 50x25 mm (Forged) | 50x25 mm (Forged) | 50x25 mm (Forged) |
| Anchor Pin | 22 mm | 22 mm | 22 mm | 22 mm |
| Length | 2000 mm | 2457 mm | 2914 mm | 3371 mm |
| Weight | 290 kg (Approx.) | 350 kg (Approx.) | 410 kg (Approx.) | 490 kg (Approx.) |
*The weight and working data contained in the present leaflet are supplied for information only and are not binding. Specification and size can be altered as part of ongoing product modification/improvement.
